【HXY MOSFET】ESD/TVS Static Surge Protection Components - Your Trusted Choice

309 2024-08-29

In today‘s rapidly developing electronic device market, electrostatic discharge (ESD) and transient voltage spike (TVS) have become important factors affecting product reliability and service life. To address these challenges, Huaxianyang Electronics, as a semiconductor component supplier, is committed to providing high-quality and high-performance ESD/TVS protection solutions.

Product Highlights
Low capacitance series: designed specifically for high-speed data interfaces such as USB Type-C, HDMI, etc., providing fast response protection while maintaining signal integrity.
High power series: suitable for power lines and high current applications, with excellent surge absorption capability.
Integrated solution: Multiple protection channels are integrated within a single package, simplifying PCB layout and saving space.
Environmentally friendly: Made of lead-free materials, compliant with RoHS standards, reducing environmental impact.

Application case: HDMI (High Definition Multimedia Interface)

Model: HPESD4USB5B-TTS
Package: DFN2510-10L
Product Introduction: Current/A: 3, Voltage/V: 5, Junction Capacitor Typ/pF: 0.4, Number of Channels: 4, Type: Uni Unidirectional,
Specification document link: https://www.hxymos.com/esdbaohu/13923.html

Application case: Static protection for 100Mbps Ethernet

Model: SMBJ15CA
Encapsulation: SMB
Product Introduction: Current/A: 24.6, Voltage/V: 15, Number of Channels: 1, Type: Bi Bidirectional,
Specification document link: https://www.hxymos.com/esdbaohu/5343.html

Application case: USB 3.0 electrostatic discharge protection solution

Model: HSTN101050B101
Package: DFN1006-2L
Product Introduction: Current/A: 5.5, Voltage/V: 5, Junction Capacitor Typ/pF: 10, Number of Channels: 1, Type: Bi Bidirectional,
Specification document link: https://www.hxymos.com/esdbaohu/13687.html

Model: HPESD4USB5B-TTS
Package: DFN2510-10L
Product Introduction: Current/A: 3, Voltage/V: 5, Junction Capacitor Typ/pF: 0.4, Number of Channels: 4, Type: Uni Unidirectional,
Specification document link: https://www.hxymos.com/esdbaohu/13923.html

Model: HSTN061050BL15
Package: DFN0603-2L
Product Introduction: Current/A: 3, Voltage/V: 5, Junction Capacitor Typ/pF: 0.25, Number of Channels: 1, Type: Bi Bidirectional,
Specification document link: https://www.hxymos.com/esdbaohu/14315.html

Application case: SD card electrostatic discharge protection scheme

Model: HGG0402055R042P
Package: DFN1006-2L
Product Introduction: Current/A: 2.5, Voltage/V: 5, Junction Capacitor Typ/pF: 2.5, Number of Channels: 1, Type: Bi Bidirectional,
Specification document link: https://www.hxymos.com/esdbaohu/13483.html

Application case: VGA electrostatic discharge protection scheme

Model: HSTN061050BL15
Package: DFN0603-2L
Product Introduction: Current/A: 3, Voltage/V: 5, Junction Capacitor Typ/pF: 0.25, Number of Channels: 1, Type: Bi Bidirectional,
Specification document link: https://www.hxymos.com/esdbaohu/14315.html

Application case: I2C electrostatic discharge protection scheme

Model: HPESD4USB3B-TT
Package: DFN2510-10L
Product Introduction: Current/A: 4, Voltage/V: 3.3, Junction Capacitor Typ/pF: 0.6, Number of Channels: 4, Type: Uni Unidirectional,
Specification document link: https://www.hxymos.com/esdbaohu/13875.html

Application case: BNC electrostatic discharge protection scheme

Model: HESDALD03BCX
Encapsulation: SOD-323
Product Introduction: Current/A: 20, Voltage/V: 3.3, Junction Capacitor Typ/pF: 1, Number of Channels: 1, Type: Bi Bidirectional,
Specification document link: https://www.hxymos.com/esdbaohu/13237.html

Model: HSELC05CI
Encapsulation: SOD-323
Product Introduction: Current/A: 4, Voltage/V: 5, Junction Capacitor Typ/pF: 1, Number of Channels: 1, Type: Bi Bidirectional,
Specification document link: https://www.hxymos.com/esdbaohu/13413.html

Model: HSTS321080B100
Encapsulation: SOD-323
Product Introduction: Current/A: 18, Voltage/V: 8, Junction Capacitor Typ/pF: 1, Number of Channels: 1, Type: Bi Bidirectional,
Specification document link: https://www.hxymos.com/esdbaohu/13271.html

Model: GBLC12C
Encapsulation: SOD-323
Product Introduction: Current/A: 12, Voltage/V: 12, Junction Capacitor Typ/pF: 1, Number of Channels: 1, Type: Bi Bidirectional,
Specification document link: https://www.hxymos.com/esdbaohu/12667.html

Model: HGBLC15C
Encapsulation: SOD-323
Product Introduction: Current/A: 10, Voltage/V: 15, Junction Capacitor Typ/pF: 1, Number of Channels: 1, Type: Bi Bidirectional,
Specification document link: https://www.hxymos.com/esdbaohu/12649.html

Model: HESDALD18BCX
Encapsulation: SOD-323
Product Introduction: Current/A: 7, Voltage/V: 18, Junction Capacitor Typ/pF: 1, Number of Channels: 1, Type: Bi Bidirectional,
Specification document link: https://www.hxymos.com/esdbaohu/13785.html

Model: HAQ4024-01FTG-C
Encapsulation: SOD-323
Product Introduction: Current/A: 6, Voltage/V: 24, Junction Capacitor Typ/pF: 1.3, Number of Channels: 1, Type: Bi Bidirectional,
Specification document link: https://www.hxymos.com/esdbaohu/13597.html

Model: HSG3D15B36MA
Encapsulation: SOD-323
Product Introduction: Current/A: 4.5, Voltage/V: 36, Junction Capacitor Typ/pF: 0.8, Number of Channels: 1, Type: Bi Bidirectional,
Specification document link: https://www.hxymos.com/esdbaohu/13787.html

Application case: CAN electrostatic discharge protection scheme

Model: HDUP2105SOQ-7
Package: SOT-23
Product Introduction: Current/A: 5, Voltage/V: 24, Junction Capacitor Typ/pF: 25, Number of Channels: 2, Type: Bi Bidirectional,
Specification document link: https://www.hxymos.com/esdbaohu/13177.html

Model: SMAJ24CA
Packaging: SMA
Product Introduction: Current/A: 10.3, Voltage/V: 24, Number of Channels: 1, Type: Bi Bidirectional,
Specification document link: https://www.hxymos.com/esdbaohu/4515.html

Application case: Static discharge protection scheme for DC 12V power port

Model: SMBJ15A
Encapsulation: SMB
Product Introduction: Current/A: 24.6, Voltage/V: 15, Number of Channels: 1, Type: Uni Unidirectional,
Specification document link: https://www.hxymos.com/esdbaohu/5341.html

Application case: DC 24V power port electrostatic discharge protection scheme

Model: SMCJ28A
Packaging: SMC
Product Introduction: Current/A: 33.1, Voltage/V: 28, Number of Channels: 1, Type: Uni Unidirectional,
Specification document link: https://www.hxymos.com/esdbaohu/5597.html

At Huaxianyang Electronics, we are well aware that every project is unique. Therefore, we not only provide standard products, but also support customized development based on customers‘ specific needs. We will spare no effort to provide you with the best ESD/TVS protection solution. Contact us immediately to make Huaxianyang Electronics your trusted partner
